Expanded Vertical Capacity, Modular Design
The Paragon Caldera XL Dual-Media Multipurpose Kiln is built for artists, educators, and studios who want expanded vertical firing space in a compact tabletop kiln. With a 7.5" W x 7.5" D x 9" H firing chamber firing up to 2,350°F, the Caldera XL delivers fast heat-up and precise digital control for ceramics, fused glass, enameling, PMC firing, porcelain, china painting, and mixed-media work.
L-shaped notched firebrick corner joints add long-term structural strength beyond typical mitered or butted brick designs, and a reversible firebrick base extends durability over time. Like the original Caldera, the XL is fully modular and compatible with Paragon's optional expansion collars — Caldera-X for additional depth, Caldera-BC with a bead door for annealing mandrels, and Caldera-E for added enameling height.
Included with every order
SENTINEL Touch Xpress touchscreen controller, instruction manual, and 2-year limited warranty. Also available in a 240V single-phase configuration — contact us for details. Optional high-temperature viewing window and lid safety switch available.
Key Features
- 7.5" x 7.5" x 9" chamber firing up to 2,350°F — extra vertical room for taller molds, layered kiln furniture, and dimensional projects
- 2.5" insulating firebrick with L-shaped notched corner joints for excellent heat retention and long-term structural strength
- Top-fired heating element in recessed grooves for even heat and extended element life
- Reversible firebrick base extends long-term durability
- Modular two-piece design compatible with Caldera-X, Caldera-BC, and Caldera-E expansion collars
- SENTINEL Touch Xpress touchscreen controller with Ramp-Hold programming for glass, ceramics, metal clay, and mixed-media schedules
- Sheathed Type-K thermocouple and rugged steel stand with rubber feet
- Optional high-temperature viewing window for glass artists, or a lid safety switch for added safety
Specifications
| Interior Dimensions | 7.5" W x 7.5" D x 9" H |
| Cubic Feet | 0.29 |
| Overall Dimensions | 17" W x 20" D x 17.5" H |
| Max Temperature | 2,350°F / 1287°C |
| Voltage | 120V (single phase) |
| Amps | 15A |
| Watts | 1,800 |
| Plug Configuration | NEMA 5-15 |
| Breaker Size | 20A |
| Approx. Ship Weight | 75 lbs |
